System Type : 15″, 2-way, bass-reflex
Frequency Range (-10 dB) : 70 Hz - 20 KHz
Frequency Response (±3 dB) : 82 Hz - 20 KHz
Sensitivity (1w/1m) : 99 dB
Nominal Impedance : 8 Ohms
Maximum SPL : 127 dB (133 dB peak)
Power Rating
(Continuous/Program/Peak) : 350 W/700 W/1400 W
Coverage Pattern : 70° x 60° (H x V)
Dimensions (H x W x D) : 680 mm x 430 mm x 430 mm
26.8 in x 16.9 in x 16.9 in
Net Weight : 19.9 Kg (43.9 lbs)
LF Driver : 1 x JBL 265H-1
HF Driver : 1 x JBL 2408H-1
Input Connectors : 2 x Neutrik® Speakon® NL4MP
Enclosure Construction : Trapezoid, 18 mm, plywood
