System Type : 12″, 2-way, bass-reflex
Frequency Range (-10 dB) : 71 Hz - 20 KHz
Frequency Response (±3 dB) : 90 Hz - 20 KHz
Sensitivity (1w/1m) : 97 dB
Nominal Impedance : 8 Ohms
Maximum SPL : 124 dB (130 dB peak)
Power Rating
(Continuous/Program/Peak) : 350 W/700 W/1400 W
Coverage Pattern : 70° x 60° (H x V)
Dimensions (H x W x D) : 600 mm x 350 mm x 382 mm
23.6 in x 13.8 in x 15.0 in
Net Weight : 14.7 Kg (32.5 lbs)
LF Driver : 1 x JBL 262H-1
HF Driver : 1 x JBL 2408H-1
Input Connectors : 2 x Neutrik® Speakon® NL4MP
Enclosure Construction : Trapezoid, 15 mm, plywood
