System Type : 8″, 2-way, bass-reflex
Frequency Range (-10 dB) : 70 Hz - 20 KHz
Frequency Response (±3 dB) : 78 Hz - 18 KHz
Sensitivity (1w/1m) : 86 dB
Nominal Impedance : 8 Ohms
Maximum SPL : 110 dB (116 dB peak)
Power Rating
(Continuous/Program/Peak) : 150 W / 300 W / 600 W
Coverage Pattern : 120° x 100° (H x V)
Dimensions (H x W x D) : 235 mm x 435 mm x 295 mm
9.3 in x 17.1 in x 11.6 in
Net Weight : 8.1 Kg/PC (18 lbs/PC)
LF Driver : 1 x 8″ WF
HF Driver : 2 x 1″ silk dome tweeter
Input Connectors : Binding post
Enclosure Construction : Vinyl covered 12 mm MDF
