System Type : 10″, 3-way, bass-reflex
Frequency Response (±3 dB) : 65 Hz - 16 KHz
Sensitivity (1w/1m) : 89 dB
Nominal Impedance : 8 Ohms
Maximum SPL : 111 dB (117 dB peak) @ 1m
Power Rating
(Continuous/Program/Peak) : 150 W/300 W/600 W
Recommended amplifier power : 180W - 250W @ 8 ohms
Coverage Pattern : 150° x 120° (H x V)
Dimensions (H x W x D) : 290 mm x 506 mm x 320 mm
11.4 in x 20 in x 12.6 in
Net Weight : 12.4 Kg (27.3 lbs)
LF Driver : 1 x 10″ Woofer
MF Driver : 2 x 3″ paper cone midrange drivers
HF Driver : 2 x 3″ paper cone tweeters
Input Connectors : Binding post
Enclosure Construction : Vinyl covered 12 mm MDF
Suspension Attachment : 2 x M10 threaded hardware
